제품 상세 정보:
|
| 패널 크기: | 5.7 인치 | 해결: | 320×240 |
|---|---|---|---|
| 표면: | 안티 섬광 | 명암비: | 350:1 (Typ.) |
| 주파수: | 60 hz에서 | ||
| 하이 라이트: | industrial lcd screen,industrial lcd panel |
||
Resolution 320×240 TX14D12VM1CAA 5.7 inch Contrast Ratio 350:1 (Typ.) Display Colors 262K (6-bit)
TX14D12VM1CAA Basic Information
| Panel Model | TX14D12VM1CAA |
| Panel Brand | HITACHI |
| Descrition | a-Si TFT-LCD ,5.7 inch, 320×240 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Remarks | LTS|4wt|AG|WTR, Introduced 5/24/2006 |
TX14D12VM1CAA Mechanical Features
| Dot Resolution | 320(RGB)×240 (QVGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 70 PPI |
| Aspect Ratio | 4:3 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.120×0.360 mm (H×V) |
| Pixel Pitch | 0.360×0.360 mm (H×V) |
| Weight | 200g (Typ.) |
| Surface | Antiglare |
| Active Area | 115.2×86.4 mm (H×V) |
| Bezel Area | 119.4×90.6 mm (H×V) |
| Outline Dimension | 131×102.2 mm (H×V) |
| Outline Depth | 12.4 (Typ.) mm |
| Holes & Brackets | Rear mounting holes (4-Ф2.4) |
| Landscape or Portrait | Landscape type |
| Touch Panel | Embeded (4-wire Resistive) |
TX14D12VM1CAA Optical Features
| Display Mode | TN, Normally White, Transmissive |
| Brightness | 280 cd/m² (Typ.) |
| Contrast Ratio | 350 : 1 (Typ.) (Transmissive) |
| Display Color | 262K (6-bit) |
| Response Time | 45 (Typ.)(Tr+Td) |
| Viewing Angle | 65/65/70/50 (Typ.)(CR≥5) (L/R/U/D) |
| Viewing Direction | 6 o'clock |
| White color Chromaticity | Wx:0.290; Wy:0.290 |
| Sunlight Readable | N |
Guarantee:
(1) All items will be strictly tested and shipped with safe & professional package.
(2) We have 12 months warranty for each LCD screen panel, depend on the different LCD panel models.
(3) We will do our best to solve any possible problems for your after sale sevice. Please contact with us if any problems.
Competitive Advantage:
1. Rich experience.
Having been specialized in this field for years, we have rich experience and widespread sales network around the word.
2. Great quality and high purity
Good quality is one secret for our success.
3. Safest and fastest delivery.
We have mass stock, so that we can arrange the delivery within 24hours once receiving the payment. Tracking number would be informed quickly after shipment.
4. Good after-sales service.
24/7 is available. Try our best to solve various problems customers encountered!
TX14D12VM1CAA Backlight System
| Lamp Position | Edge light type |
| Lamp Type | CCFL |
| Lamp Amount | 1 pcs |
| Lamp Shape | L shape |
| Lamp Life Time | 50K(Min.) (Hours) |
| Lamp Voltage | 760V (Typ.) |
| Lamp Current | 2.0/5.0/6.0mA (Min./Typ./Max.) |
| Lamp Operating Frequency | 55KHz (Typ.) |
| Lamp Startup Voltage | 1300V (Min.)(Ta=5℃) |
| Interface Type | Connector |
| Lamp Driver Board | No |
